规格

• Product Type: USB To Specific Interface Conversion Cable
• Cable length: 0.3 m
• Specifications: [USB]
• Interface Standard: Compliant with USB Specification Ver. 3.2 Gen1 (USB3.1/3.0)
• 5Gbps, 480Mbps, 12Mbps, 1.5Mbps
• USB3.2 Gen1 (3.1/3.0) Type-C connector Male (upstream), USB Type-C (PC side)
• Power supply: Self-power and bus power compatible * When using the PD-compatible AC adapter or PD-compatible AC adapter supplied with the PC, the AC adapter can be d as self-power. *If you an AC adapter of 45 W or less, the computer may not enter the charging mode.
• Number of Ports: Total/2 Ports [PD]
• PD Support: Support
• PD Specifications: 100 W 20 V 5 A [LAN Port]
• Standards: IEEE 802.3 (10BASE-T Ethernet), IEEE 802.3u (100BASE-TX Fast Ethernet), IEEE 802.3ab (1000BASE-T)
• Communication mode: Full duplex/Half duplex
• access methods: CSMA/CD
• Port shape: RJ-45 port (Auto MDI/MDI-X) with Auto-Negotiation
• Power supply voltage: 5V [Video output port]
• Port Shape: HDMI Type A (19pin) Female * Supports DisplayPort Alt mode * Supports HDCP1.4/2.2
• Supported resolutions: Up to 3840x2160 (4 K 30 Hz)
• Maximum supported resolution: 4 K/30 Hz
• HDCP: HDCP1.4, HDCP2.2 [Common Specifications]
• Cable Length: Approx. 30 cm
• Size: Approx. W80xD40xH14.5mm
• Weight: about 40 g
• Code: SN10S9J
