产品详细内容
产品型号: 4-3783-01
产品品牌: AS ONE Corporation
功能
- By using four discharge electrode needles, spatial ion balance is improved, and strong static elimination is possible with no wind, especially at short distances.
- Beca it does not wind and has a long ion reach, it is suitable for the elimination of charged objects in narrow or distant places.
- The discharge electrode needle has a current limiting circuit and is designed to be safe without electric shock (windless type).
- It comes with a flexible arm so that you can remove static from the target area.
- Suitable for ultra-small precision parts in part feeder, powder filling, small screen printing, pad printing, small resin molding machine, static elimination for narrow film transport and cut film transport.
- Beca of the breeze, there will be no splattering of samples. With flexible arms.
- Suitable for wind-averse processes beca of the breeze.
规格
- Body size (mm): 74 x 58 x 54
- Weight (g): Body/180, including flexible arm/about 450
- Static elimination system: DC corona discharge
- Antistatic effective range: distance/50 ~ 300 mm, area/250 mm radius from front center
- Ozone generation: 0.02 ppm or less (measuring distance: 300 mm)
- Alarm indication: Power light off in case of high-voltage circuit failure
- Flexible length: 250 mm
- Power supply: 100 VAC 50/60 Hz (using dedicated adapter)
- Power consumption: about 1.1 W
- Accessories: Dedicated adapter
