规格

• Display: 3 5/6 digits
• Count: 6000
• measurement range
• DC Voltage: 60.00 mV/600.0 mV/6.000 V/60.00 V/600.0 V/1000 V
• AC Voltage: 600.0 mV/6.000 V/60.00 V/600.0 V/750 V
• DC Current: 60.00uA/600.0uA/60.00 mA/600.0 mA/20.00 A
• AC Current: 60.00uA/600.0uA/60.00 mA/600.0 mA/20.00 A
• Resistance: 600.0 Ω/6.000 kΩ/60.00 kΩ/600.0 kΩ/6.000 MΩ/60.00 MΩ
• Capacitance: 60.00 nF/600.0 nF/6.000uF/60.00uF/600.0uF/6.000 mF/60.00 mF
• Frequency: 9.999 Hz/99.99 Hz/999.9 Hz/9.999 kHz/99.99 kHz/999.9 kHz/9.999 MHz
• Duty ratio: 0.1~99.9%(Typical values: Vrms=1 V, f=1 kHz)/0.1~99.9% (>1 kHz)
• Temperature: -50 °C to +400°C
• Functions: Flashlight, Backlight, Diode Test, Auto Power Off, Data Hold, Low Battery Display, Auto Range
• Safety Standard: CAT04 600 V, CAT03 1000 V
• Power supply: 9V battery x 1 (for testing)
• Size: 89 x 190 x 56 mm
• Weight: 360 g
• Accessories: Test lead, K thermocouple
• resolution
• DC Voltage: 0.01 mV/1 mV/1 V
• AC Voltage: 0.1 mV/1 mV/1 V
• DC Current: 0.1uA/0.01 mA/0.01 A
• AC Current: 0.1uA/0.01 mA/0.01 A
• Resistance: 0.1 Ω/0.01 MΩ
• Capacitance: 0.01 nF/0.1uF
• Frequency: 0.001 Hz
• Duty ratio: 0.10%
• Temperature: 1 deg.
• Accuracy
• DC Voltage: ± (0.5%±2digit)/± (0.5%±2digit)/± (0.8%±2digit)
• AC Voltage: ± (0.8%±2 Digit)/± (0.8%±2 Digit)/± (1%±3 Digit)
• DC Current: ± (0.8%±2digit)/± (0.8%±2digit)/± (1.2%±3digit)
• AC Current: ± (0.8%±2 Digit)/± (0.8%±2 Digit)/± (1.2%±3 Digit)
• Resistance: ± (0.8%±2digit)/± (2%±3digit)
• Capacitor Capacity: ± (2.5%±3digit)/± (3%±5digit)
• Frequency: ± (0.8%±2 digits)
• Duty ratio: ± (1.2%±3digit)/± (2.5%±5digit)
• Temperature: ± (2.5%±3digit)/± (4.5%±5digit)
• Calibration Items: DC Voltage, DC Current, DC Resistance, AC Voltage 50 Hz, AC Current 50 Hz
