产品详细内容
产品型号: 63-6875-50
产品品牌: XP Power
功能
- XP Power-JSE08 Series Insulated DC-DC Converter
- The JSE08 series from XP Power is a reliable and stable single/dual output, 8W insulated DC-DC converter. This series of products is designed to be packaged in a DIP16 package, has a 2:1 input range, and complies with all ITE safety approvals. These compact DC-DC converters also have a high power density, a breakdown voltage of 1500 V dc, and a wide operating temperature range of -40 to +105 °C.
- 8 W Insulated DC-DC Converter 2:1 Input Range Stable Single/Dual Output DIP16 Package 1500 V dc Insulation Voltage ITE Safety Approved Wide Operating Temperature Range: -40 → +105 °C
规格
- Quantity: 1 piece
- Output Voltage: 24 V dc
- Input voltage range: 18 to 36 V dc
- Input voltage nominal: 24 V dc
- Rating Power: 8W
- Output current: 335 mA
- Mounting type: through hole
- Number of outputs: 1
- Efficiency: 86%
- Package: DIP 16
- Minimum temperature: -40 degrees C
- Maximum temperature: + 105 degrees C
- Width: 13.7 mm
- RoHS compliance status: Compliance
- Securities Code: 123 -1171
