产品详细内容
产品型号: 63-6851-28
产品品牌: XP Power
功能
- XP Power-ECM60 Series AC-DC Power Supply
- The XP Power ECM60 Series offers a variety of open-frame 60 W AC-DC power supplies. All of these products are approved by the IT/Healthcare industry. All of these reliable, compact power supplies have a Class I or Class II structure. This series of products is convectively cooled and has an operating temperature range of 0 to +70 °C.
- Open-frame, 60 W power efficiency: 80 ~ 85% IT/Healthcare approved Class I/Class II structural DC input version available (DCM series) 3 year warranty
规格
- Quantity: 1 piece
- Output Voltage: 7V dc
- Output Current: 8.6 A
- Rating Power: 60 W
- Number of outputs: 1
- Input Voltage: 120 to 370 V dc, 90 to 264 V ac
- Mounting Type: Chassis Mount
- Package Type: Open Frame
- Length: 101.6 mm
- Width: 50.8 mm
- Depth: 27 mm
- Weight: 150 g
- Maximum temperature: + 70 degrees C
- Medical standards certification: Yes
- RoHS compliance status: Compliance
- Securities Code: 122 -7079
