产品详细内容
产品型号: 63-4901-68
产品品牌: KOA
功能
- AEC-Q200 Certified 0603 Thick Chip Resistor, RK73H Series 1% KOA's RK73H Series Precision Resistor is a compact and lightweight solution.
- This precision resistor with a three-layer electrode structure has excellent reliability and high stability.
- The use of metal glaze thick film provides excellent weather and heat resistance.
- This precision resistor is ideal for both flow and reflow soldering and is used in automatic mounting machines.
- All RK73H chip resistors except the 01005 case size are AEC-Q200 certified and suitable for automotive applications.
- Small, lightweight, stable and reliable lead-free terminal jumper resistor is also included.
规格
- 数量:1袋 (50个)
- 电阻:330 kΩ
- 技术:厚膜
- 包装/外壳:0603
- 容忍度:±1%
- 额定功率:0.1 W
- 温度系数:±100 ppm/deg。
- 尺寸:1.6 x 0.8 x 0.45 mm
- 深度:0.8 mm
- 工作温度最小值:-55°C
- 工作温度mAx:+155°C
- 外壳样式:模具
- RoHS合规性状态:合规性
- 证券代码:631 -6991
