65-3904-45 ［Discontinued］Digital Oscilloscope with General Calibration (Inspection Report + Tresability Structure) « Frequency Band: 25 MHz Input: 2ch Maximum Sampling Rate: 250 MS/s » AD5143-00A00
产品描述
产品型号: 65-3904-45产品品牌: A&D 功能 Comes with a certifica […]
联系我们
产品详细内容
产品型号: 65-3904-45
产品品牌: A&D
功能
- Comes with a certificate of general calibration.
- It can be used for student experiments in physics, electrical and electronic engineering, and science at universities, high schools, and junior high schools, for research, development, and manufacturing facilities, and for inspection and maintenance of electrical and electronic facilities.
- A digital storage oscilloscope that pursues basic instrumentation with simple operation that is easy to see and use
- Frequency Band: 25 MHz.
- Maximum sampling rate: 250 MS/s (1 channel).
- With 6-digit frequency counter function, calculation function and automatic measurement function.
- Waveform and panel settings save/call function (up to 20 sets can be saved/called in the internal memory).
- With pass/fail judgment function.
- 7-inch color LCD display.
- It has a USB port.
规格
- Frequency Band: 25 MHz
- Maximum sampling rate: 250 MS/s (1 channel), 125 MS/s (2 channels)
- Input channels: 2 channels
- Memory record length: 512k
- Vertical axis input sensitivity: 1 mV/div to 20 V/div (1-2-5 steps)
- Horizontal axis time axis sensitivity: 10 ns/div to 50 s/div (1-2-5 steps)
- Display: 7-inch color LCD
- External dimensions/mass: 306 (W) x 147 (H) x 122 (D) mm (excluding protrusions)/approx. 2.2 kg
- Power supply: [Input voltage] 100~240VACrms (50~60 Hz), 100~120VACrms (400 Hz)
- Power consumption: up to 100VA
- Accessories: Power Cable, 2 Probes, Quick Guide
- *The client name and address on the certificate will be blank.
- *The delivery time will be around 2 weeks because we will proofread your order after it is confirmed. (However, please note that it takes additional days for the New Year's holiday and the New Year holiday.)
- *As this is a made-to-order product, we cannot accept cancellations, returns or returns after ordering.
