产品详细内容
产品型号: 64-2544-09
产品品牌: A&D
功能
- [Applications]
- Inspection and diagnosis of electrical equipment, inspection and diagnosis of air conditioning equipment, inspection and diagnosis of buildings and houses, food field Brewing, fermentation, temperature distribution measurement of aging process (evaluation of uniformity), physical and thermal analysis medical field
- [Features]
- Visualization of temperature distribution with thermal image, recording of temperature data
- Thermal image, visible image (digital camera image), thermal image + visible image (FUSION image), temperature distribution data (32×32=1024 csv temperature data file), video video can be saved on Micro SDHC card
- Setting menu can be selected from Japanese, English, French, German, Dutch, Portuguese, Italian, Spanish, Chinese (simplified/traditional)
规格
- 测温范围:-20~350°C
- 温度分辨率:0.1°C
- 测量 (响应) 波长:8~14μm
- 发射率设置:0.10到1.00以0.01为增量
- 热像分辨率:32 x 32像素 (32 x 32红外温度传感器)
- 存储卡:Micro SDHC卡 (4 GB到32 GB)
- 数据存储:多达10万个数据 (png格式的图像文件存储在空白的16 GB Micro SDHC卡上)
- 数据存储项目:热图像、可见图像、热图像+可见图像、视频、温度分布 (数字) 数据 (32×32像素)
- 电源:内置可充电锂离子电池 (DC 3.7 V/2600 mAh) ，不可更换
- 连续使用时间:最长3小时 (充满电时) ，环境温度:25°C,无数据存储操作，无报警操作
- 附件:业主手册，手提箱，微型SDHC卡，USB电缆
