规格

• Specifications: Deep
• External dimensions (mm): 1200 x 900 x 1950
• Internal dimensions (mm): 950 x 675 x 1750
• Weight (approx. kg): 165
• Number of pieces: 1
• Exterior: Steel (powder coating finish)
• Interior: Chemical and heat resistant board (flame retardant, phenolic resin laminate)
• Work surface: not attached
• Lifting sash: Tempered glass (5 mm thick) with balance-weight aperture restriction key (400 mm high), handle/ABS resin
• Hydrant: not included
• Outlet: Not included
• Outlet: 100 VAC -15 A with 2 serial grounding
• Lighting: LED Fluorescent
• Operating switch: Touch-panel lighting/fan
• Safety features: Exhaust airflow indication
• Exhaust connection: PVC (Polyvinyl Chloride Resin) volume damper with phase flange
• Power connections: terminal block with electrical box
• (Exhaust)
• Working sash opening height (mm): 400
• Controlled wind speed (m/s): 0.5
• Airflow (m3/min): 13
• Duct connector: 200 A
• Required duct diameter (phi mm): 200
• (Ancillary facilities)
• Fluorescent (light): 20 W x 2 light equivalent
• Outlet (location): 2
• *Shipping, carrying-in, installation and assembly costs are required separately. Please inquire.
• *Exhaust fan is not included. Please inquire.
