产品详细内容
产品型号: 1-5238-31
产品品牌: AS ONE Corporation
功能
- Since forward and reverse operation can be switched, it can be used for temperature control of cooling equipment as well as heating equipment such as heaters.
- 4~20 mA analog data output (external leads required).
规格
- 温度设定范围 (摄氏度) :0到200
- 小显示单位 (C度) :1
- 显示精度:±3°C (包括传感器误差) (需要外部导线)
- 控制方法:ON/OFF控制
- 温度感应器:Pt 100Ωφ4 x 200 mm缆线长度2 m
- 输出方法:通过继电器触点从主机侧面的3P插座输出电压
- 额定输出:AC100V 50/60 Hz MAX 12 A (电阻负载)
- 安全功能:过电流保护保险丝 (15 A) ，断开时的传感器烧坏电路
- 资料输出:4至20 mA (固定-10至+240°C) 类比输出
- 尺寸:95 x 150 x 47公厘 (移除投影)
- 电源线长度:2.0公尺 (3 P插头)
