产品详细内容
产品型号: 2-4404-01
功能
- The water in the sensor is absorbed to the outside and the internal pressure is lowered, and this pressure can be used to determine the moisture content of the soil.
- Parts such as tank, pipe, porous cup and negative pressure sensor can be detached.
- Built-in air tank allows measurement without water supply for a long time.
- Negative pressure sensors have high accuracy and excellent environmental resistance.
规格
- 罐体尺寸 (毫米) :φ50×85
- 管路长度 (mm) :200
- 测量方法:张力计方法
- 测量范围:0-100kPa
- 作业温度范围:0 -60°C (请勿冻结)
- 罐单元材料:丙烯酸
- 管路规格:φ18mm (PC (聚碳酸酯) )
- 孔杯规格:φ18mm (氧化铝，莫来石)
- 接头金属配件:不锈钢 (SUS304)
- O形圈材料:NBR (丁腈橡胶) ，
- 压力传感器:不锈钢结构压力传感器
- 液体连接材料不锈钢(SUS316L,SUS316)、丁腈橡胶、
- 电源:DC12-28V
- 消耗电流:6mA以下
- 输出电压:DC1-2V
- 准确度:±0.5% FS或更低(线性:±0.3% FS或更低)
- 电缆:φ6乙烯基×10 m
- 结构:IP65
- 型号:HD-001-0200-10
