产品详细内容
产品型号: 68-1816-46
功能
- Stackable
- TP Standard A container standard developed jointly with major automobile manufacturers to maximize logistics efficiency. By standardizing the design of containers = modularizing and developing size variations according to the standard, all containers can fit together. Since stable stacking is possible even in containers of different sizes, it is possible to load them without gaps in trucks, etc., and there is no waste of distribution costs. The TP standard can be extended to two-color containers (SN containers) and Container to further improve distribution efficiency.
- Compatible with 3 types of handle cover It is possible to install "3 types of handle cover" which closes the handle hole only by sandwiching 2 types of parts from inside and outside. Can be easily detached without tools to prevent contents from popping out, dust and foreign matter from mixing.
- Hand Hole
规格
- Manufacturer: Sanko
- Model number: 206900
- Product name: TP364
- Capacity: 68.5 L
- External Dimensions (mm): 670 x 335 x 380 (H)
- Color: Ash
- Inner Dimensions (mm): 635 x 300 x 368 (H)
- Effective Inner Dimensions: 626 x 291 x 358 mm
- Compression load: 18.13 kN (1850kgf)
- Material: Polypropylene
- Weight (g): 2520
- Bottom Shape: TP Grid Rib Sunbox (sticky container) TP Standard (container standard developed jointly with major automobile manufacturers to maximize logistics efficiency) The bottom shape is adopted for containers. The convex shape of the bottom surface, which is designed based on the TP standard, makes it possible to interfit all kinds of TP standard containers, and stable fitting is possible for containers of different sizes as well as well as well. The SF (case) type has a lattice rib (a plate shape erected perpendicular to the plane in order to reinforce the plane) structure in the convex shape of the bottom, and shows high strength. On the other hand, the inner bottom of the container is flat.
- Number of Bottom Blocks: 8
