产品详细内容
产品型号: 68-1814-95
功能
- This type is used for stacking sanklets with a Lid, and can be stacked via a Lid attached to the container body. The Lid can be opened and nesting (storage) can be done in the condition of an empty box, and the storage place of the empty box and transportation cost can be reduced. Since the Lid and main body of the are integrated, there is no disconnection or loss due to vibration. The Lid has a corrugated shape that can be combined with the open type. Secrecy is further enhanced by stacking with the Lid closed.
- Stackable
- Interlocking is possible, and rational distribution can be achieved by using combinations.
规格
- Manufacturer: Sanko
- Model number: 203852-01
- Product Name: Sancret #38
- Capacity: 37.4
- External Dimensions (mm): 506 x 333 x 325
- Material: Polypropylene
- Inner Dimensions (mm): 450 x 297 x 305
- Effective Inner Dimensions: 420 x 267 x 289 mm
- Color: Blue
- Weight (g): 2040
- Compression load: 7.55 kN (770kgf)
- Nesting height: 90 mm
- Bottom Shape: Grid Rib A grid rib (a plate shape erected perpendicular to the plane to reinforce the plane) is installed on the bottom surface. The rib height determines the bending strength, and the higher the rib, the higher the strength. It is often used in industrial containers, especially in industries that use oil, and it has the effect of suppressing deflection due to swelling (a phenomenon in which resin absorbs oil, etc., and the volume increases).
