规格

• Function: DC voltage, AC voltage, DC current, AC current, resistance, capacitance, DUTY, frequency, diode, conduction
• detection methods: true RMS
• Display: 6000 counts, bar graph 61 segments
• Sampling: approx. 3 times/second
• Power supply: 2 AAA batteries
• Battery Life: Approximately 100 hours of continuous use (alkaline battery)
• Open Clamp Diameter: Φ12 mm
• Size (W x D x H): Approx. 81 x 30 x 128 mm
• Weight: about 210 g (without batteries)
• Calibration certificate with JCSS certified symbol: with
• *I have attached the calibration certificate which was subjected to JCSS calibration test at the time of shipment.
• *JCSS certified calibration certificates with symbols can meet the requirements of standards such as ISO/IEC 17025, the international standard for testing laboratories and calibration organizations, ISO9000S, the international standard for quality systems, and IATF 16949 (ISO/TS 16949), the quality system for the automotive industry.
• Calibration Contents DC Voltage, AC Voltage 50 Hz Resistance * Although this product comes with a clamp, DC and AC current calibration is not supported.
