产品详细内容
产品型号: 67-8735-81
产品品牌: Kett Electric Laboratory
功能
- Eddy current film thickness meter for measuring thickness of urethane waterproof layer (laid with non-magnetic metal sheet)
- Model for Thick Film Measurement (0~12 mm)
- Dedicated Eddy Current Probe Included
- Comes with a pressure dispersion plate that is easy to peel off from the urethane waterproof layer
规格
- Measurement Method: Eddy Current Method
- Probe: Probe for Urethane Waterproof Layer Thickness Meter
- Measurement object: Insulating coating on non-magnetic metal
- Measurement Range: 0~12 mm
- Measurement accuracy: < 1 mm/±0.03 mm, ≥ 1 mm/±3%
- Resolution: Less than 10 mm/0.01 mm, More than 10 mm/0.1 mm
- Number of data memories: Approx. 8,000 points
- Application memory: 100
- Display Method: Digital (Backlit LCD, Minimum Display Digit 0.01 mm)
- External Output: PC (USB or RS-232C)
- Power Supply: 1.5 V Battery (AA Alkali) x 4
- Power consumption: 130 mW (backlight off)
- Battery life: 100 hours (Continuous use when backlight is off)
- Operating Temperature Range: 0~40°C
- Additional functions: 16 functions
- Dimensions/Weight: Body: 75 (W) x 145 (D) x 31 (H) mm, 0.34 kg
- Probe: Φ42 x 103 mm, 0.17 kg
- Accessories: Aluminum Fabric, Pressure Dispersion Plate, Standard Plate (Set of 5), Batteries 1.5 V (AA Alkali) x 4, Soft Case, Instruction Manual
- Options: Standard Plate (Thickness other than accessories), Personal Computer Cable, RS-232C-USB Cable, Data Management Software: Data Logger LDL-03
