规格

• Application: Durable Type
• Pressure load range: 20~5000
• Maximum rotational shaft torque (N · m): 3
• Friction force range (N · m): 0.02~3
• Shaft speed (rpm): MAX3350
• Slip speed range (cm/sec): 0.6~400 when using standard ring specimens
• Maximum continuous operation time (hr): 1000
• Drive motor: AC servomotor
• Adaptive specimens: rings, discs, pins
• Operation: Color Touch Panel
• Display: Pressure detection value, friction force, rotation speed, pseudo wear amount, test time, manual operation command button, rotation/stop
• Temperature indicator: For test specimens, temperature indicator 0~300°C, compatible with K thermocouple (sheath diameter Φ1 mm)
• Automatic pressurization mechanism: yes
• Automatic operation end setting and operation: Operation time, automatic test stopped after decompression work according to various limit conditions
• Automatic stop (no abnormal stop or decompression work at the time of stop): motor abnormality, pressure full scale over, friction force full scale over, pressure movement upper and lower limit
• Load Detector: Load Cell Type 5 kN (for Pressurization)/1 kN (for Pressurization)/100 N (for Pressurization/Friction)/20 N (for Friction)
• Pressure Spring: 3 Types for 5 kN, 1 kN, and 100 N
• Power (Cable length 5 m, Cable diameter Φ3): 200 VAC, 6kVA
• Ground fault breaker: included
• Body Dimensions: W630 x D660 x H1600mm
• Body mass: 350 kg
