规格

• Size: 210 x 88 x 230 mm
• Weight: 3 kg
• Accessories: Dedicated 4 conductor resistor temperature sensor, power cord, communication cable, USB-RS232 C converter, dedicated software (AMS-200), instruction manual, warranty, JCSS calibration certificate (calibration points 0, 100, 200, 300, 400, 420°C)
• Input: Pt100Ω JIS C 1604 4 Conductor Type
• Measurement Range (°C): 0~500
• Accuracy: ± (0.05% of reading+0.05) °C
• Measured current (mA): 1
• Sampling frequency: 1 second
• Display: Green 7-segment LED 6 digits
• Resolution: 0.001 °C, 0.01 °C, 0.1°C Switch
• Filter: Moving average count up to 1~10
• Communication Specifications: RS-232C 9600bps
• Operating Power: 100 VAC ±10% 50/60Hz
• Operating conditions: 10~40°C, 0~80%RH or less (However, there must be no condensation.)
• Storage conditions: 0~50°C, 0~80%RH or less (However, there should be no condensation.)
