产品详细内容
产品型号: 65-1918-66
产品品牌: A&D
功能
- I see strength! Tabletop tensile compression test with high performance and low test force type (test force display resolution: 0.001 N).
- Color touch panel provides good visibility and easy operation.
- It comes with a high-precision load cell, and you can use it as soon as you turn on the power.
- Test speed can be easily set digitally.
- Displacement display is provided as standard.
- Comes standard with PC installation software.
- The jig (attachment) used in the force gauge and push-pull gauge can also be used. *M6 screws are used when using the M6 onesideadapter.
- It is connected to the mini printer AD-8126 (sold separately) and can print out the maximum load and displacement.
- Space-saving design that can be used on a desk.
- A force measuring machine that replaces the force gauge and push-pull gauge.
- Can handle a variety of material tests.
规格
- 大测试功率:500 N
- 十字轴冲程:370 mm
- 有效行程 (使用标准平行夹紧下巴时) :285 mm
- 十字头速度范围:10~300 mm/min:在设定值的5%以内± (空载)
- 交叉速度和测试力容量:可以在所有速度范围内测试 大测试力容量
- 位移显示:0.00毫米( 小0.01毫米:0.1毫米以上100毫米)
- 测试力测量精度 (使用500 N负载单元时) :500 N~50 N/±0.2%F.S,指定值50 N~5 N/±2%，5 N以下/±0.1 N以下
- 测试力测量精度 (使用50 N负载单元时) :50 N~5 N/±0.2%F.S,指定值5 N~0.5 N/±2%，0.5 N以下/±0.01 N以下
- 测试力指示分辨率 (使用500 N负载单元时) :0.01 N (超过100 N时为0.1 N指示)
- 测试力指示分辨率 (使用50 N负载单元时) :0.001 N (超过10 N时为0.01 N指示)
- 外形尺寸/质量:250 (W) x 405 (D) x 711 (H) mm/18 kg
- 附件:业主手册，500 N装载盒，50 N装载盒，PC软件(CD-ROM:MSAT-Lite)，USB电缆
- 不防水。
- *不防水。
