产品详细内容
产品型号: 65-1845-67
产品品牌: Sato Keiryoki Mfg. Co., Ltd.
功能
- Temperature data logger that can store up to 16,000 measurement data- The temperature sensor uses Pt (platinum temperature measuring resistor) for high-precision low-temperature measurement.
- Of the Pt sensors, JIS A Class/4-wire type is used to guarantee high accuracy. * Up to 2 temperature sensors can be connected. * Analysis software is standard included. * Soft features. * Up to 10 indicators can be connected at the same time using a USB hub. * Graph display, storage, printing, and analysis (Expansion, reduction, period selection, integrated temperature analysis function, etc.) can be performed. * Data can also be saved in CSV format. * Real-time monitoring, real-time monitoring, and alarm settings can be set. Warning email can be sent to pre-registered email addresses. * Key-lock function prevents misoperation during storage. Upper and lower alarm values can be set. (LED on when alarm is activated) * Either battery or AC adapter (sold separately) can be used. * When used together, AC adapter takes priority. When the power supply stops from the AC adapter due to power failure or other reasons, the battery automatically switches to the battery. - Even if the power is turned off, the stored measurement data is stored in the internal memory. - In addition to downloading the stored measurement data to a PC, the stored measurement data can be copied to a microSD memory card (sold separately).
规格
- Securities Code: No. 8850 - 00
- Temperature sensor: 4-wire platinum thermometer resistor (Pt 100 ohm)
- Measuring range: - 99.9 ~ 600.0 deg. C * Measuring range depends on connected sensor.
- Resolution: 0.1 degrees C
- Indicator accuracy: +/- 0.2 degrees C (at 0 ~ 40 degrees C), +/- 0.3 degrees C (except at left) * Total accuracy is calculated by adding the accuracy of the connected sensors.
- Display function: Temperature/humidity alarm (ALM), storage method, status display (REC/RES), memory size (bar), SD memory, low battery mark, key lock mark, each error message, setting value display at each setting
- Number of storage channels: Temperature 2 channels
- Storage capacity: 16000 data per channel
- Memory interval: 1 second, 2 seconds, 5 seconds, 10 seconds, 15 seconds, 30 seconds, 1 minute, 2 minutes, 5 minutes, 10 minutes, 15 minutes, 30 minutes, 60 minutes, 14/90 streets
- External memory: microSD, SDHC/up to 32 GB. *Commercially available memory must be pre-formatted. The format supported by this instrument is FAT 32 format. NTFS format not accepted
- Dustproof and waterproof: JIS 0920 IP 65 compliant * SK-L 753 to 1/2 When connected to sensor, both without AC adapter
- Operating environmental conditions: - 10 ~ 60 degrees C, 85% rh or less (no condensation)
- Power supply: 2 AA alkaline batteries or dedicated AC adapter (optional)
- Battery life: When in measurement mode/approximately 500 hours, when in storage mode/capable of storing 16,000 data at each interval (when LCD is off) We recommend the use of an AC adapter when in constant LCD display or measurement mode.
- Material: PC (Polycarbonate)
- Dimensions: (W) 114 x (H) 80 x (D) 35 mm (excluding projections)
- Weight: approx. 230 g (battery included)
- Accessories: 2 AA alkaline batteries, 1 communication cable (1.5 m), 1 instruction manual, 1 quick manual, 1 analysis software CD-ROM, 1 communication cable, 1 PT sensor connection box for L 753
- Operating System: Windows 10/8. 1/8 (all 64 bit/32 bit Japanese versions) * Install the latest service pack.
- Other memory 4 GB or more (32 bit) 8 GB or more (64 bit) Hard disk must have at least 4 GB of free space USB port and CD-ROM drive. Internet connection and email address are required to use mail alert function Optional: No. 8229 -50 dedicated AC adapter (cable 1.5 m)
- *Since the sensor is not included, purchase an optional sensor separately.
