产品型号: 64-5053-01
产品品牌: SEKISUI
功能
- Plastic valve with excellent corrosion resistance. Can be used safely without being corroded by acidic or alkaline chemicals or seawater.
- Plastic valve with excellent corrosion resistance. Can be used safely without being corroded by acidic or alkaline chemicals or seawater.
- Optimized diaphragm and weir shape provide low torque and high sealing performance.
- The handle is equipped with a diaphragm protection over-tightening prevention mechanism and an indicator showing the opening.
- Suitable for a variety of piping such as chemical piping in chemical factories, pure water piping in semiconductor factories, seawater piping in fishery factories, and wastewater treatment lines in food factories.
规格
- PVC Pipe Nominal Diameter: 125
- Maximum Working Pressure (MPa): 0.8 MPa/Fluid: Water/20°C
- Fluid Temperature (°C): 60°C/Fluid: Water
- Material: Body Hard Vinyl Chloride Tube (PVC) Diaphragm: EPDM
- Body: PVC
- Flange Type Nominal Diameter: 125 mm
- H:560mm
- Diaphragm: EPDM
- There are other connection methods: screw type and TS type.
- L:410mm
- Body: PVC
- Material: Body Hard Vinyl Chloride Tube (PVC) Diaphragm: EPDM
- Also available are body materials: HT, PP and PVDF.
- In addition, we also have PTFE and C-PE, so please use them according to your application.
- JIS10K Flange
- Material/Finish: Hard Polyvinyl Chloride (PVC)
- Country of Origin: Taiwan
- Securities Code: 850-6059
- There is a separate shipping fee for Hokkaido, Okinawa and remote islands.
