产品详细内容
产品型号: 64-0829-32
产品品牌: ICHINEN TASCO CO., LTD.
功能
- True effective value pocket size tester
规格
- 测量范围
- 直流电压:600 mV/6/60/600 V (输入阻抗:10 MΩ)±0.8% rdg±5 dgt (600 mV/6/600 V) ±1.0% rdg±5 dgt
- 交流电压:600 mV/6/60/600 V (输入阻抗:10 MΩ)±1.3% rdg±5 dgt (6/60 V) (50/60 Hz) ±1.7% rdg±5 dgt (6/60 V) (45至500 Hz) ±1.6% rdg±5 dgt (600 V) (50/60 Hz) ±2.0% rdg±8 dgt (600 V) (45至500 Hz)
- 电阻:600Ω/6/60/600 kΩ/6/40 MΩ±1.0% rdg±5 dgt (600Ω/6/60/600 kΩ/6 MΩ) ±2.5% rdg±5 dgt (40 MΩ)
- 电导率:600Ω (蜂鸣器声音小于或等于60Ω)
- 适用标准:IEC 61010 -1 CATII 300 V CATII 600 V IEC 61010-031、IEC 61010-033、IEC 61326 -2 -2
- 使用电池:硬币型锂离子电池CR 2032 (3 V x 1)
- 尺寸:W 85 x D 18 x H 126 mm
- 质量:约135克(硬壳，包括电池)
