产品详细内容
产品型号: 63-4660-03
产品品牌: RS PRO
功能
- Square Pads and Metal Foil Laminate Holes
- Metal foil laminates allow you to place wires in the same hole as the tail of the component to ensure a reliable solder connection.
- DIN41612 connectors with 96/96 contacts are attached at both ends.
- The entire length of the board is equipped with power rails.
- The earth plane ensures maximum shielding on the component side.
规格
- 侧数:双面
- 孔距:2.54 x 2.54 mm
- 尺寸:233.4 x 220 mm
- 长度:233.4毫米
- 宽度:220 mm
- 基材:环氧玻璃基材
- 孔径:1.02mm
- FR材料等级:FR4
- 铜厚度:35μm
- 连接:DIN 41612
- 代码号:110-2517
