产品详细内容
产品型号: 63-4656-44
产品品牌: TE Connectivity
功能
- UL, CSA
- TE Connectivity Universal MATE-N-LOK Free Hanging Plug Connector Housing
- For wire-to-wire or wire-to-board applications, this 6.35 mm pitch spaced universal MATE-N-LOK plug housing product can be cable or panel mounted. These universal MATE-N-LOK plug housings are made of UL94V-2 or UL94V-0 nylon. A snap-lock latch ensures accurate engagement with reliable quick release and polarization.
- These universal MATE-N-LOK plug housings can accommodate pin or socket contacts. For the best contact, the part number; For crimping tools see 720-2133 720-2133 etc., part number; See 849-114 849-114. For die sets, part number; See 849-136 849-136, etc. For strain relief clamps, the representative part number; See 302 0120 302 0120.
规格
- Number of pieces: 1
- Number of contacts: 9
- Number of lines: 3
- Gender: Male
- Mounting Type: Panel Mount
- Series: UniversalmATE-N-LOK
- Compatible products: 6.35 mm center-line soft-shell pin and socket connector
- Body orientation: straight
- Length: 27.38 mm
- Depth: 27.43 mm
- Housing Material: Nylon
- RoHS compliance status: Compliance
- Securities Code: 848 -880
