产品详细内容
产品型号: 62-6085-34
产品品牌: A&D
功能
- It is a roller conveyor type check scale that accurately performs judgment processing at high speed for weighings of large weight and volume.
- It is a high cost performance checker with a convenient weighing check mode that suits the application such as automatic stopping of non-conforming products and packaging function on a weighing conveyor.
规格
- 大重量:15公斤
- 选择精度:±10 g
- 小规模:2 g
- 滚子速度:11.2 m/min (50Hz) 、13.4 m/min (60Hz)
- 能力:18张/分 (50Hz) 、22张/分 (60Hz)
- 大测量尺寸
- 长度: (流向) 300 mm (50Hz) 、280 mm (60Hz)
- 宽度:350 mm
- 高度:300 mm
- 输送:驱动滚子系统 (钢制)
- 电源:
- 驱动辊部分:200 VAC,±10%，50/60 Hz,3相，0.5 A
- 显示:AC100V+10% -15%，50/60 Hz,约。30伏安
- *安装调整费和运费另外收取。
- * 需要在交货前讨论规格。
