规格

• Length (m): 10
• Inner diameter (mm): 25.4
• Outer Diameter (mm): 35.5
• Working pressure (MPa): -0.05~0.2
• Allowable bend radius (mm or more): 195
• Operating temperature range: -30~100°C
• Compliant with Food Sanitation Law (2012 the Ministry of Health, Labour and Welfare Notification No. 595)
• FDA (Food and Drug Administration) registration
• Color: Milky white
• Color: Milky white/with green line
• Material/Finish: Main Material/Silicone Rubber, Reinforcement/Special PET Resin
• Do not for medical purposes.
• Use the hose within the operating temperature and pressure ranges. However, never for steam, animal or vegetable oil over 70°C.
• The hose expands and contracts due to internal pressure, so make sure to leave plenty of room for piping.
• When pressurizing, open and close the valve slowly so that shock pressure is not applied.
• Do not directly soak the end face or fitting of the hose in the fluid (food, chemicals, etc.) in the tank. Fluid may seep into the hose reinforcement layer or remain in the joint, causing the propagation (adhesion) of bacteria and deterioration of the hose.
• Country of origin: Japan
• Securities Code: 195-2790
