产品详细内容
产品型号: 65-9006-87
产品品牌: NITTO KOHKI CO., LTD.
功能
- For low pressure.
- Has pressure resistance performance equivalent to that of metal.
- Plug and socket connection is a one-touch connection by simply pushing in.
- Its weight is only about 1/4 of that of metal, so it is light and easy to handle.
- Fluid adapts to water as well as air.
- Fluid can flow from both the plug side and socket side.
- Compatibility: Can be connected to "High Coupler" models 10, 17, 20, 30 and 40. Can be connected to products of the "High Coupler" series (except 400, 600, and 800 models) and the "Nat Coupler" series.
规格
- Opposing Hose Size (mm): Φ5 x Φ8
- Mass (g): 14
- L(mm):119
- ΦD(mm):23
- H (mm): Hex 19
- A(mm):90
- ΦB(mm):4
- Valve Structure: One Way Opening/Closing Type
- Applied fluids: Air, Water
- Body Material: Engineering Plastic (POM)
- Maximum Working Pressure (MPa{kgf/cm2}): 1.0{10}
- Pressure Capacity (MPa{kgf/cm2}): 1.5{15}
- Recommended maximum tightening torque range (N · m{kgf · cm}): 1.6~2.0{16~20}
- Type: Plug
- Specifications: Resin Plug/Spring Nut Type
