产品型号: 63-4593-43
产品品牌: RS PRO
功能
- VDE, FIMKO
- Certification applies only to 6 A and 10 A types.
- High Performance
- RF filter that achieves high attenuation performance in both differential mode and common mode Ideal for industrial frequency converters, motor drives and switch mode power supply applications
- X2 class and Y class safety suppression capacitors combined with high inductance toroidal choke.
- This combination provides high performance, especially in applications with high interference frequency and intensity. For electrical connections, soldering 250 (1/4 inch) size terminals or push-on receptacles are d. Connectors - see Terminal/Test Lead section
规格
- 大电流等级:10A
- 大电压等级:250 V交流电
- 安装类型:底盘安装
- 终止样式:标签
- 系列:TFNF
- 工作频率:400Hz
- 长度:90 mm
- 深度:52 mm
- 电容:0.47 x 2μF, 22 x 2 pF
- 尺寸:90 x 52 x 40 mm
- 低工作温度:-25°C
- 高工作温度:+85°C
- 电阻:220kΩ
- 代码号:240-725
