产品详细内容
产品型号: 1-6236-04
产品品牌: OVAL Corporation
功能
- Compact and lightweight vortex flowmeter using piezoelectric element sensor.
- With the of a battery-powered system, you can monitor the instantaneous flow rate and cumulative value simply by installing it in the piping.
- The structure has no moving parts, so it has excellent durability.
- The display can be rotated in a direction that is easy to see.
- Can also be d for various stains (water stains, rust, algae, etc.) of circulating cooling water.
规格
- 型号:FLM22-10PCW
- 流速范围 (L/min) :8.3 -133
- 公称直径，连接:25mmφR 1, 1/4公螺纹
- 应用流体:液体/水、气体/空气、氮
- 大工作压力:0.98MPa
- 精度:全尺寸+/- 3%
- 压力损失:水/0.12-34.3kPa,大气压空气/0.06-1.52kPa
- 显示 (LCD数字显示) : (1) 累积积分8位数 (2) 每小时瞬间流量5位数 (3) 每分钟瞬间流量5位数 (4) 复位积分7位数外部模式切换可以切换 (1) - (4) 流量单位{L, kL, g, kg, ns, L (正常) ， kL (正常)}和小数点显示在LCD (可自由更改显示方向360°)
- 电源 (电池供电) :锂电池单元寿命:4年 (但在室温下) ...具有降电池报警功能
- *流速是水的值。
