功能

• Material: Pin Portion: Phosphorus Bronze Resin Portion: PBT Black (UL94V-0) Treatment: Pin Portion Nickel Underlay Gold Plating Print Plate Mounting Hole Diameter: 1.0~1.1φ
• Rated Current: 3 A
• Rated Voltage: 250 V AC. DC
• Insulating Resistance: 500 MΩ or More
• Voltage: 1000 V AC. DC1 Minute
• Operating Temperature Range: -40°C to +125°C
• Number of Pieces: 10
• These are 2.54 mm pitch connected type wrapping terminals. ・Switch can be switched in combination with a jump socket (part number JS-1). In this case, the height from the printed circuit board surface is 6 mm. (Combination of WL-1 and JS -1) ・34 pins are connected, so please cut it to the desired number of poles with a mold cutting nipper (part number MOC-3) and it.
